Features:
1. Intelligent Drive-monitoring System
The digital intelligent drive-monitoring system of our diesel forklift truck can facilitate obtaining the operation data of the diesel forklift easily, so as to achieve the whole-process control of the forklift.
2. Full Hydraulic Flexible Steering System
The full hydraulic steering system of our diesel forklifts can greatly reduce the fatigue of the operator. The steering system uses a horizontal oil cylinder on the compact steering axle and guarantees a reliable steering.
3. Classical Space Frame Structure
Our diesel forklift truck uses the classical YTO ASF space frame structure. It is ergonomically designed, aesthetic in appearance, compact in structure, and easy to operate.
4. Good-view Mast
The optimized rail section design of the mast enables the driver to enjoy a good and wide view.

Technical Specifications:
Model: CPCD25
Power Type: Diesel
Rated Capacity: 2500kg
Load Center: 500mm
Lifting Height: 3000mm
Mast Tilt Angel (F/R): 6/12Deg
Front Overhang: 465mm
Wheel Base: 1600mm
Wheel Tread (F/R): 960/970mm
Dead Weight: 3720kg
Free Lift Height: 160mm
Min. Turning Radius: 2240mm
Min. Ground Clearance - Under Mast: 105mm
Min. Ground Clearance - Wheelbase Center: 150mm
Service Brake: Hydraulic-Foot Pedal
Parking Brake: Mechanical-Hand Lever
Lifting Speed (full-load/no-load): 550/600mm/s
Lowering Speed: Full-load < 600mm/s, No-load > 300mm/s
Travel Speed (full-load/no-load): 18/19km/h
Max. Gradeability (full-load): 20%
Max. Tractive Force (full-load/no-load): 17/13kN
Weight Distribution with load (F/R): 5220/1000kg
Weight Distribution without Load (F/R): 1410/2310kg
Engine Model: C490BPG
Engine Manufacturer: XINCHANG
Engine Rated Power: 40kW/2650rpm
Max. Torque/rpm of Engine: 162N•m/1800rpm
Engine Displacement: 2.54L
Battery Voltage: 12V
Battery Capacity: 100Ah
Gearbox Transmission Type: Hydraulic torque converter
Gear Shift (F/R): I/I
Tyre Type: Pneumatic Tyres
Tyre Model – Front: 7.00-12-12PR
Tyre Model – Rear: 6.00-9-10PR
Fork Dimension: 40x125x1070mm
Overall Length (without Fork): 2600mm
Overall Width: 1150mm
Overall Height Mast Extended: 4030mm
Overall Height Mast Lowered: 2000mm
Overall Height Overhead Guard: 2120mm

Note:
1. Technical specifications are for standard models only.
2. Other optional accessories, functions and requirements are available upon request.
3. All specifications and design characteristics are subject to change without prior notice.

Optional Engine:
Model: C240
Manufacturer: ISUZU
Rated Power: 34.5kW / 2500rpm
Max. Torque: 134 N•m /1800rpm
Displacement: 2.369L
